Rear combination lamp LZD 2252

Upgrade your vehicle’s rear lighting with the HOR 86A Dual-Function Rear Combination Lamp from Horpol. Designed to deliver both rear fog light and reversing light functions in one compact LED unit, this versatile lamp improves safety, visibility, and compliance for commercial and utility vehicles.

Equipped with 12 high-performance LEDs (6 red and 6 white), the HOR 86A ensures bright, reliable illumination in all working conditions. The integrated fog light enhances rear visibility in poor weather, while the powerful reversing light provides clear illumination when manoeuvring.

With E9 ECE R23/R38 approval, IP68 protection, and compatibility with both 12V and 24V systems, this lamp is built for professional use in demanding environments. It can be mounted vertically or horizontally, making it a flexible solution for trucks, trailers, agricultural machinery, and construction vehicles.

It also serves as a perfect complement to the LZD 2246 lamp, creating a cohesive rear lighting setup.

Key Features:

• Dual-function rear fog light + reversing light
• LED technology with 12 total LEDs (6 red, 6 white)
• Compatible with 12V and 24V systems
• E9 ECE R23/R38 approved
• Can be mounted vertically or horizontally
• Durable, weather-resistant design – IP68 rated
• Wide operating temperature range (-30°C to +50°C)
• Universal mounting application
• Ideal complement to LZD 2246 lamp
• 1 metre cable for flexible installation

Specifications:

• Model: HOR 86A
• Lamp Category: Combined rear lamp
• Functions: Reversing light + Fog light
• Light Source: LED
• Number of LEDs: 12 (6 red, 6 white)
• Supply Voltage: 12V / 24V
• Operating Temperature: -30°C to +50°C
• Protection Rating: IP68
• Mounting: Universal (vertical or horizontal)
• Cable: 3 × 0.5 mm²
• Cable Length: 1 m

Wire Markings:

• White – Ground (mass)
• Blue – Reversing light (1.5 / 3.1 W)
• Red – Fog light (2.5 / 3.1 W)
